Description
| Order Code | HS1B5NV130D024 |
|---|---|
| Weight | 100 g |
| Quantity per Package | 1 |
| Multiple Qty. of Packs per Order | 1 |
| Package Dimensions | 75 × 49 × 38 mm |
| Volume | 139.65 cm³ |
| Bar Code (EAN13) | 8013975321676 |
| HS Code | 85365003 |
| Type of Product | Hockey Puck, Single-phase |
|---|---|
| Control Voltage | 3.5–32 VDC |
| Rated Operational Voltage | 24–510 V |
| Rated Operating Current AC-51 (Resistive Load at 40°C) |
130 A |
| Rated Operating Current AC-53 (Motor Load at 40°C) |
32 A |
| Heatsink Requirement | ≤ 0.3°C/W (for use at 40°C and 55°C at rated AC-51 current) |
| Number of Poles | 1 |
| Maximum Operating Temperature | +90°C |
| Specific Let-through Energy (I²t) | 22 |
| Terminal Type | Screw |
| Order Code | HS1B5NV130D024 |
|---|---|
| Weight | 100 g |
| Quantity per Package | 1 |
| Multiple Qty. of Packs per Order | 1 |
| Package Dimensions | 75 × 49 × 38 mm |
| Volume | 139.65 cm³ |
| Bar Code (EAN13) | 8013975321676 |
| HS Code | 85365003 |
